The NOVOTEST EDDY SENSE is a high-precision, portable magnetic eddy current flaw detector designed to identify and evaluate the depth of stress corrosion cracks as small as 2 microns. It is capable of detecting flaws in materials even under non-metallic coatings or corrosion. Featuring an intuitive, user-friendly interface with visual and audible alarms, it allows operators to quickly set alarm thresholds and adjust material settings with a single button press. Ideal for shop and field non-destructive testing (NDT) applications, it offers robust IP54 protection and extended battery life.
• Detects flaws in materials under non-metallic coatings or corrosion
• Identifies and evaluates stress corrosion cracks as small as 2 microns
• Auto setup and easy-to-use interface
• Quick adjustment of material settings with a single button press
• Customizable audio and light alarm thresholds for defects
• Visual and audible alarms for immediate defect notification
• Web-friendly firmware update interface
• Rugged plastic body with shockproof silicone case (IP54 rated)
• Identifies and evaluates stress corrosion cracks as small as 2 microns
• Auto setup and easy-to-use interface
• Quick adjustment of material settings with a single button press
• Customizable audio and light alarm thresholds for defects
• Visual and audible alarms for immediate defect notification
• Web-friendly firmware update interface
• Rugged plastic body with shockproof silicone case (IP54 rated)
|
Parameter
|
Value
|
|---|---|
|
Minimum Crack Opening
|
2 µm
|
|
Minimum Depth
|
0.3 mm
|
|
Scanning Speed (Min)
|
50 mm/s
|
|
Frequency Range
|
1 MHz to 3.5 MHz
|
|
Languages
|
English, Ukrainian, Russian (others by request)
|
|
Protection Level
|
IP54 (dust and moisture resistant)
|
|
Body Type
|
Plastic with shockproof silicone case
|
|
Power Supply
|
2 × AA batteries / AA charger
|
|
Battery Life
|
20 hours
|
|
Operating Temperature
|
-20°C to 50°C
|
|
Operating Humidity
|
<95% R.H. at 35°C
|
|
Dimensions
|
122 × 76 × 37 mm
|
|
Weight
|
0.25 kg (with batteries)
|
